Electromagnetic speed sensor Nasa Eml-3

NASA

Electromagnetic speed sensor kit + control box for NASA Clipper Duet display. Target. Singray.

With the NAS-NEML-3 kit. which includes a control box and an electromagnetic probe. you can convert speed displays (loch) NASA like Target 2. Clipper. Clipper Duet and Stingray.

Mount the control box in a dry place below deck and replace the probe with the new electromagnetic one. The new probe is magnetic. has no moving parts. thus avoiding mechanical failure.

Technical information

The control box converts the sensor signal into pulses, enabling it to be connected to any Clipper display. Clipper Duet. Target2 or Stingray.

• Speed range 0.2 to 40 knots
• Transducer outer diameter: 50 mm
• Cable length: 5 m
• Calibration of the measured speed can be performed directly via the control box.
• The electromagnetic transducer is profiled. A 50 mm OD assembly skin is included and must be inserted in place of your current installation.

This electromagnetic log is only suitable for composite hulls.
